The Flight Series - Reliable high up
Jump starter for small aircraft
Semi-automatic booster
Technical features
- Tension-free plugs, through built-in switch
- Built-in fuse, short-circuit protection against overload and to protect the battery against destruction
- Reverse polarity protection, indication by LED
- Surge Protection
- Starts possible without on-board battery
- Charge level indicator
- with an intelligent charger, 3-stage charging technique
XPS 12-1 flight
- 600 A/ 12 V
- Piston engines up to 300 HP
Automatic booster
Technical features
- Fully automatic start equipment with intelligent electronics
- Electronics and surge protection
- Reverse polarity protection
- automatic test availability of portable batteries
- Deep discharge protection
- Lead-gel batteries, which are used by NATO global
- High current plug connector, for several start and adapter cable - WITHOUT adapter cable
- Intelligent charging system for the continuous availability of the equipment
- Starts possible without on-board batteries
XPA 12-2 flight
- 1200 A/ 12 V
- Piston engines up to 600 HP
XPA 12/24-2 flight
- 1200 A/ 12 V
- 800 A/ 24 V
- Piston engines up to 600 HP (12 V) and 500 HP (24 V)
XPA 12/24-4 flight
- 1600 A/ 12 V
- 1200 A/ 24 V
- Piston engines up to 600 HP (12 V) and 500 HP (24 V)
XPA 12/24-4/3 flight
- 2400 A/ 12 V
- 1200 A/ 24 V
- Piston engines and turbines up to 2000 HP (12 V) and 1000 HP (24 V)
XPA 12/24-6 flight
- 1800 A/ 12 V
- 1800 A/ 24 V
- Piston engines and turbines up to 2000 HP (12 V) and 1000 HP (24 V)
XPA 12/24-6/3 flight
- 3600 A/ 12 V
- 1800 A/ 24 V
- Piston engines and turbines up to 2000 HP (12 V) and 1500 HP (24 V)
Booster Equipment
Booster equipment adapter cable - cable length 2 m
Pole clamps
- angled
- 35mm² / 50mm²
Plug
- 2 poles
- 35mm² / 50mm²
Plug connection
- for Piper
- 35mm² / 50mm²
Plug connection
- for Cessna
- 35mm² / 50mm²
Technical Details
| Typ | XPS 12-1 flight | XPA 12-2 flight | XPA 12/24-2 flight | XPA 12/24-4 flight | XPA 12/24-4/3 flight | XPA 12/24-6 flight | XPA 12/24-6/3 flight |
|---|---|---|---|---|---|---|---|
| Output voltage: | 12 V/ DC | 12 V/ DC | 12 und 24 V/ DC | 12 und 24 V/ DC | 12 und 24 V/ DC | 12 und 24 V/ DC | 12 und 24 V/ DC |
| Battery size: | 1 x 16 Ah | 2 x 16 Ah | 2 x 16 Ah | 4 x 16 Ah | 4 x 16 Ah | 6 x 16 Ah | 6 x 16 Ah |
| Battery manufacturer: | Hawker | Hawker | Hawker | Hawker | Hawker | Hawker | Hawker |
| Starting current 12 V: | 600 A | 1200 A | 1200 A | 1600 A | 2400 A | 1800 A | 3600 A |
| Shortcircuit current 12 V: | 1800 A | 3600 A | 3600 A | 4400 A | 4400 A | 5200 A | 7600 A |
| Starting current 24 V: | 800 A | 1200 A | 1200 A | 1800 A | 1800 A | ||
| Shortcircuit current 24 V: | 1800 A | 3600 A | 3600 A | 5200 A | 5200 A | ||
| Piston engines 12 V: | 300 HP | 600 HP | 600 HP | 1200 HP | 2000 HP | 1800 HP | 3600 HP |
| Turbines 12 V: | 1200 HP | 2000 HP | 1800 HP | 3600 HP | |||
| Piston engines 24 V: | 500 HP | 1000 HP | 1000 HP | 1800 HP | 1800 HP | ||
| Turbines 24 V: | 1000 HP | 1000 HP | 1800 HP | 1800 HP | |||
| Dimensions: | 270 x 230 x 130 | 430 x 200 x 300 | 430 x 200 x 300 | 1000 x 200 x 300 | 1000 x 200 x 300 | 1000 x 200 x 300 | 1000 x 200 x 300 |
| Cable length / cable cross section: | 1,20 m - 1,40 m | 2,00 m/ 35 mm² | 2,00 m/ 35 mm² | 2,00 m/ 50 mm² incl. chassis | 2,00 m/ 50 mm² incl. chassis | 2,00 m/ 50 mm² incl. chassis | 2,00 m/ 50 mm² incl. chassis |
| Weight: | 10 kg | 16 kg | 16 kg | 33 kg | 33 kg | 45 kg | 45 kg |
